DNP3 Outstation RTU IED Server Simulator

Add up to 50 server node in the simulator. Every server node will work independently.

Simulator window shows the status & connection port number.

The user can update the monitoring Point information.The following parameters can change Value and quality bits.

DNP3 Outstation RTU IED Server Simulator

Features

  • Multiple Server Simulation

  • Supports Serial, TCP IP Communication

  • Level 3 Compliance

  • Supports File Transfer ( File read, file write), Directory commands.

  • Supports unsolicited response, Octect String, Virtual Terminal Output

  • Supports "Select-Before-Operate" and "Direct-Execute" command execution modes

  • Support Binary Output(CROB) and Analog Output Commands

  • Supports, frozen counter input, frozen analog input typeids,

  • device attributes support

  • Solicited and unsolicited reporting

  • Generate analog point changes

  • Generate binary point changes (single/1-bit and double/2-bit)

  • Generate counter "counts"

  • Process counter freeze operations

  • Time Clock Syncronization

DNP3 Protocol Outstation RTU Server Simulator User Manual

Download Evaluation Kit - DNP3 Protocol Development Bundle

In the Development Bundle, We included DNP3 Outstation Server Simulator, Master Client Simulator, Windows , Linux SDK, Source code available - C, C++, C# .net core, Python Programming
